Solaris-At-4800-80 Auger

Industry Leaders: Solaris Auger Torque Drives for 21MT to 45MT Excavators

Optimize Excavation with Solaris Auger Torque Drives

Excavation and drilling tasks demand precision and power. At Solaris, we’ve engineered Auger Torque drives tailored for 21 to 45-ton (46,000 – 100,000 lb.) excavators. These drives are all about performance, meticulously crafted from premium-grade materials and subjected to stringent quality checks to ensure reliability and efficiency in the field.

Versatile Auger Drives for Various Excavation Needs

Our Auger Torque drives are versatile companions, seamlessly integrating with a diverse array of excavator models. This adaptability allows swift attachment interchangeability, allowing operators to switch drill bits between different attachments. This seamless transition translates to superior performance and heightened efficiency across a variety of construction and landscaping projects.

MODEL 48000-80
Carrier Weight 21-45 MT
Torque Range 24557 -49114 ft-lb
Oil Pressure Range 2321-4641 psi
Oil Flow Range 26.4-74.0 gpm
Speed Range 8-21 rpm
Hub Options 4.33 inch Square
Unit Height 61.26 inch
Shaft 4.33 inch Square
Hitch Options Single Pin Hitch
Double Pin Cradle Hitch
Valve Options 2 Way Valve – Converts single acting hammer into a 2 way auxiliary flow

Auger Torque’s Auger Drives are built to the most exacting standards using only high-quality materials and the latest manufacturing techniques available.

FORGED HOOD EARS

Standard with all auger drives in areas that we know will take a lot of strain. All hood pins are locked for extra safety making it impossible for the hood to detach from your hitch.

EPICYCLIC GEARBOX

Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motor’s output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.

NON-DISLODGEMENT SHAFT

Unique to Auger Torque, the Non-Dislodgement Shaft is a single-piece drive shaft assembled top down and locked into the auger drive housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers, a MUST-HAVE FEATURE for any safety-conscious company.

HIGH-QUALITY HYDRAULIC MOTORS

Auger Torque’s huge buying power means we work closely with high-quality suppliers to develop the most reliable attachments available on the market today.

HOSES AND ADAPTORS

All auger drives come standard with high-quality hoses and adaptors (excludes larger units. QRC’s not included).

All Solaris-Auger Torque attachments and equipment are warranted to be free from material, mechanical, or workmanship defects for a certain time (summarized below).

Planetary Gearbox: 72 months

Hydraulic Motors: 36 months

Other Parts and Products: 24 months

Note: The warranty is only valid if the product is attached, assembled, and used appropriately, according to the directions provided in the operator’s manuals and other instructions. The warranty period will start from the date of sale by the distributor or manufacturer.

Ready to place an order? Please be sure to fill out the appropriate measurement form and email it to dar@solarisattachments.com

Questions? Call us at (888) 754-3609.

Fillable SOLARIS HITCH SPECIFICATION FORM

  • CAT 320
  • CAT 321
  • CAT 323
  • CAT 324
  • CAT 325
  • CAT 326
  • CAT 328
  • CAT 329
  • CAT 330
  • CAT 335
  • CAT 3336
  • CAT 245B
  • CASE CX220E
  • CASE CX300E
  • CASE CX245D
  • CASE CX365E
  • CASE CX350D
  • DEVELON DX225LC
  • DEVELON DX235LCR
  • DEVELON DX300LC
  • DEVELON DX360LC
  • DEVELON DX400LC
  • HITACHI ZX210LC
  • HITACHI ZX245USLC
  • HITACHI ZX250LC
  • HITACHI ZX300LC
  • HITACHI ZX345USLC
  • HITACHI ZX350LC
  • HYUNDAI HX210
  • HYUNDAI HX220
  • HYUNDAI HX235
  • HYUNDAI HX260
  • HYUNDAI HX300
  • HYUNDAI HX330
  • HYUNDAI HX380
  • JOHN DEERE 200G
  • JOHN DEERE 210
  • JOHN DEERE 245
  • JOHN DEERE 250
  • JOHN DEERE 300
  • JOHN DEERE 345
  • JOHN DEERE 350
  • JOHN DEERE 380
  • KOBELCO SK230
  • KOBELCO SK270
  • KOBELCO SK380
  • KOMATSU PC45
  • KOMATSU PC50
  • KOMATSU PC210
  • KOMATSU PC238
  • KOMATSU PC240
  • KOMATSU PC290
  • KOMATSU PC360
  • KOMATSU HB365
  • KOMATSU PC390
  • SANY SY215C
  • SANY SY6225C
  • SANY SY265C
  • SANY SY335C
  • SANY SY365C
  • Volvo EC160E
  • Volvo EC200E
  • Volvo EC220E
  • Volvo EC235E
  • Volvo EC355E
  • Volvo EC380E
  • Volvo EC480E

FIND THE QUALITY ATTACHMENT YOU ARE LOOKING FOR

Get a quote

Auger Drive 48000-80: Superior Performance

Among our wide range of drives, the Auger Drive 48000-80 stands as a great example of efficiency. Housing all standard features from our lower series while offering many options, including the Solaris Auger Torque 2-Way Valve and Pressure Relief Valve, this drive is engineered for exceptional performance. Notably, high-quality hoses come standard; however, quick couplers are not included. Our recommendation is direct plumbing, eliminating flow restrictions and ensuring peak performance.

Optimal Performance and Adaptability

Solaris Auger Torque drives boast adaptability across a broad spectrum of excavators, ensuring compatibility and seamless attachment integration. Our diverse range of drives equips operators to navigate excavation projects efficiently, optimizing productivity and performance on-site.

Empowering Your Excavation Projects

Our commitment can be seen in the durability and adaptability of Solaris Auger Torque drives. With features like the 2-Way Valve and Pressure Relief Valve options, along with high-quality hoses, these drives feature optimal functionality, performance, and adaptability. They streamline excavation operations, enhancing efficiency and productivity in the field, where you need it the most.

Redefining Drilling Efficiency

Solaris Auger Torque drives redefine the standards of heavy-duty excavation tasks, guaranteeing performance and adaptability at the same time. The 48000-80 model, tailored for excavators within the 21 to 45-ton (46,000 – 100,000 lb.) range, signifies precision, durability, and flexibility.

Application in Various Excavation Scenarios

These Auger Torque drives excel in a number of excavation tasks, from foundation drilling and soil sampling to trenching and excavation for utilities. Their adaptability across diverse projects, including construction, landscaping, and utility works, emphasizes the flexibility and efficiency they bring to each job site.

Up Your Excavator Game

Solaris Auger Torque drives offer the reliability and adaptability essential for heavy-duty excavation tasks. Their compatibility with a myriad of attachments ensures superior performance across multifaceted construction and landscaping projects. Elevate your excavation efficiency today with our dependable and versatile Auger Drives. Call us today at (888) 754-3609 or sales@solarisattachments.com or fill out the form below.

Auger digging up ground
close up view of auger digging into ground
